Features & Specifications

• Sensor
  • Type: Uncooled VOx Infrared Detector, 8 to 14μm
  • Resolution: 640×512@12μm
  • NETD: 20mK
  • Frame rate: 50 Hz
• Lens
  • Objective lens: 35mm, F1.0
  • Field of view: 12.5°×10.0°
  • FOV m@100m: 22×17
  • Magnification: 1.7x~13.6x
  • Detection range: 1800m/1950yd
• Display
  • Display type: 0.39'' AMOLED 1440×1080
  • Color palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
  • Eyepiece: Eye relief: 48 mm; Diopter ± 4; Zoom: 14x
• Hardware
  • WIFI: 2.4G
  • Interface: USB Type-C; Micro HDMI
  • Tube diameter: Standard 30 mm
  • Others: Microphone, Bluetooth
• System
  • Recording function: Photo/Video (Audio recording included)
  • Memory capacity: 128GB
• Power
  • Battery type: Single 18650 battery (built-in) and customized battery (external)
  • Operating time: 12 hours
• Environmental
  • Operating temp.: -30°C to 50°C / -22°F to +122°F
  • Recoil Rating: .300 Win Mag
  • Shock: 800G at 1ms half sine pulse (as per IEC60068-2-27)
  • Encapsulation: IP67
• Physical
  • Weight (g/oz): 971/34.25
  • Size (mm/in): 368×106×68/14.49×4.17×2.68
  • Standard: Device, Lens cover, Eye mask, 5V2A adapter (US, Britain, Australia and Europe), Customized battery×2, Customized battery charger, USB Type-C cable, Micro HDMI cable, Clip×2, Quick start guide, Warranty card
  • Optional: Bluetooth remote control, Customized battery
