The Streamlight 69501 TLR-1 HL-X USB Rechargeable Multi-Fuel Light 1500 Lumen / 20,000 Candela is engineered for high-output performance and maximum adaptability. This multi-fuel light features a hinged face cap with robust release controls, enabling quick front-loaded battery changes without detaching the light from your firearm. Delivering 1,500 lumens and 20,000 candela when powered by two Streamlight SL-B9® proprietary lithium-ion rechargeable battery packs, it also operates seamlessly with two CR123A batteries. The TLR-1 HL-X offers customizable rear paddle switches, momentary and constant-on activation, and a programmable strobe mode, making it a versatile solution for tactical, duty, or personal defense needs.
Specifications:
- Case: Body and face cap: 6000 Series machined aircraft aluminum with black anodized finish. Switch housing: Impact- and chemical-resistant engineered polymer. Dimensuions:
- Width: 1.44 in
- Length: 3.45 in
- Height: 1.44 in
- Weight: 5.19oz
- Lens: High temperature, shock-mounted, impact-resistant BOROFLOAT® glass.
- Light Source: White LED, impervious to shock with a 50,000-hour lifetime.
- Light Output: SL-B9®: 1,500 lumens, 20,000 candela peak beam intensity, and 283m beam distance. CR123A: 1,000 lumens, 15,000 candela peak beam intensity, and 245m beam distance. Custom reflector produces a concentrated beam with optimum peripheral illumination. Optimized electronics provide regulated intensity.
- On/Off: Rear switches left and right of trigger guard provide ambidextrous operation (available with standard and extended actuators). Momentary and constant on operation. User-activated strobe.
- Run Time: SL-B9®: 60 minutes continuous operation to 10% output level. CR123A: 90 minutes continuous operation to 10% output level.
- Battery: SL-B9®: (2) Streamlight Li-Ion 850mAh USB-C rechargeable battery packs with integrated safety circuit, rechargeable up to 500 cycles. Charges within 2.5 hours via USB-C cord or optional bank charger. CR123A: (2) 3-volt CR123A lithium batteries with a storage life of 10 years.
- Features: High-lumen output with the included SL-B9® Li-Ion rechargeable battery pack, the TLR-1 HL-X USB offers versatile multi-fuel capability, operating on either SL-B9® batteries or standard CR123As. It features ambidextrous controls for ease of use, a one-handed snap-on and tighten system that keeps your hands safely away from the muzzle during installation or removal, and securely fits a wide array of firearms using the provided key kit. Extensively live fire tested for proven reliability, it performs in temperatures from -4°F to +120°F with SL-B9® batteries and down to -40°F with CR123As. The IPX7 waterproof rating protects it up to 1 meter for 30 minutes, and each unit is serialized for reliable identification.
The Streamlight TLR-1 HL-X USB Multi-Fuel Rail-Mounted Light is a robust, high-output light that delivers an outstanding 1,500 lumens and 20,000 candela for superior illumination. Engineered for adaptability, it features a hinged face cap that allows quick, front-loading battery changes without removing the light from your firearm. This versatile light runs on either the included Streamlight SL-B9® rechargeable lithium-ion battery or standard CR123A batteries. Its ambidextrous rear paddle switches provide both momentary and constant-on operation. Built from rugged 6000 Series machined aluminum with a shock-mounted BOROFLOAT® glass lens, the TLR-1 HL-X stands up to demanding conditions. Rated IPX7 waterproof, it ensures reliable performance in harsh environments, making it an essential tool for tactical, duty, or personal defense use.
