At nearly 1/4 pound lighter than the original Razor HD Gen II 1-6x24, the "E" (Enhanced) model allows for quicker transitions between targets and less arm fatigue during long days on the range. Perfect for the AR platform, the Gen II-E 1-6 is a top-tier optical solution for short to medium range tactical applications. Optically, it delivers the highest level of clarity, resolution, color accuracy, light transmission and edge-to-edge sharpness. True 1x on the low end is complimented by an ultra-forgiving eyebox with generous eye relief for a heads-up-display-like sight picture and a daylight bright illuminated center dot in the reticle for extremely fast target acquisition in close quarters. Ultra-sleek and built like a tank on a 30mm, aircraft-grade aluminum tube, the Razor HD Gen II-E 1-6x24 features ultra-low profile, capped windage and elevation turrets for streamlined performance. Zero-resettable turrets offer 50 MOA (20 MRAD) of adjustment in a single turn, ensuring ample travel.
Features
- APO System - Index matched lenses correct color across the entire visual spectrum.
- Optically Indexed Lenses - Optimize image sharpness and brightness from edge to edge.
- HD Lens Elements - Premium extra-low dispersion glass delivers the ultimate in resolution and color fidelity, resulting in high-definition images.
- XR™ Plus Fully Multi-Coated - Ultimate anti-reflective coatings on all air-to-glass surfaces provide maximum light transmission for peak clarity and the pinnacle of low-light performance.
- Plasma Tech - Cutting edge coating application process provides unparalleled coating durability and performance
- Second Focal Plane Reticle - Scale of reticle maintains the same ideally-sized appearance. Listed reticle subtensions used for estimating range, holdover and wind drift correction are accurate at the highest magnification.
- Illuminated Center Dot - Daylight bright illuminated center dot provides a precise point-of-aim in all lighting conditions.
- Locking Illumination - Locks illumination at preferred setting.
- Tube Size - 30 mm diameter provides maximized internal adjustment and strength.
- Single-Piece Tube - Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproofness.
- Aircraft-Grade Aluminum - Constructed from a solid block of aircraft-grade aluminum for strength and rigidity.
- Waterproof - O-ring seals prevent moisture, dust and debris from penetrating the binocular for reliable performance in all environments.
- Fogproof - Argon gas purging prevents internal fogging over a wide range of temperatures.
- Shockproof - Rugged construction withstands recoil and impact.
-
Hard Anodized Finish - Highly durable hard-coat anodization provides a low-glare matte surface and helps camouflage the shooter's position.
-
ArmorTek - Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt.
-
Large Diameter Turrets - Provide fast, accurate and easily read elevation and windage adjustments. Caps provide external protection for turret.
- Friction Reduction System - Heat-treated, hardened-steel pad floats on the end of the turret screw and interfaces with a hardened steel ring on the erector tube for steel-on-steel contact. Prevents galling or deformation of the erector screw contact point for superior durability and
- Turret Screws - Provides low-friction, wear-resistant performance: precision-machined from a silicon-brass alloy and treated with an advanced dry-film lubricant. Turret screw threads are precision machined to sub-2 micron tolerances (less than 78-millionths of an inch).
- Erector Tube System - Precision-machined from aircraft grade aluminum with anti-galling properties for a lighter weight, strong, durable tube. Stainless Steel offset coil spring erector biasing system withstands much higher stresses than traditional flat erector springs
- Reticle - Simple, intuitive and fast. The Vortex-exclusive JM-1 BDC reticle with illuminated center dot (designed with input from world-renowned competitive shooter, instructor and gunsmith Jerry Miculek) facilitates rapid, accurate, shooting at distances from point blank to 600 yards.
Included in the Box
- CR2032 battery
- Lens cloth
Specifications
- Magnification 1-6x
- Objective Lens Diameter 24 mm
- Eye Relief 4 inches
- Field of View 115.2-20.5 ft/100yds
- Tube Size 30 mm
- Turret Style Low Capped
- Adjustment Graduation 1/2 MOA
- Travel Per Rotation 50 MOA
- Max Elevation Adjustment 150 MOA
- Max Windage Adjustment 150 MOA
- Parallax Setting 100 yards
- Length 10.1 inches
- Weight 21.5 oz
The Vortex RZR-16008 Razor HD Gen II-E 1-6x24 Riflescope JM-1 BDC is the enhanced solution for tactical shooting. Lighter than its predecessor, it facilitates quick target transitions without tiring your arms. Ideal for the AR platform, this riflescope offers top-tier optics for short to medium range applications with unparalleled clarity, resolution, and color accuracy. The illuminated center dot ensures swift target acquisition, while the durable aircraft-grade aluminum construction guarantees reliability. With features like APO System, HD Lens Elements, and XR™ Plus Fully Multi-Coated lenses, this riflescope delivers high-definition images and peak clarity. Elevate your shooting experience with the Vortex Razor HD Gen II-E 1-6x24.
